WEG W22 IE2 GY 250S/M-04 55KW 4p B3T
Article number: 2311070013
In stock
Backorder allowed
Out of stock
The W22 IE2 GY 250S/M-04 55KW 4p B3T WEG is a high-quality industrial electric motor manufactured by WEG, a renowned brand in the industry. This item is widely used in various industrial applications, such as manufacturing, agriculture, and construction, providing efficient and reliable performance.
SKU
2311070013
€5,807.40
Excl. Tax:
€4,799.50
€5,575.62
Excl. Tax:
€4,607.95
Excl. Tax:
Excl. Tax:
Description / WEG W22 IE2 GY 250S/M-04 55KW 4p B3T
W22 IE2 GY 250S/M-4 55KW 4P B3T WEG Three-Phase Motor Base, GY 4/6: Construction Type: B3 (Foot), Efficiency Class: IE2, Height H: 250mm, Motor Size: Iec 250S/M, Series: W22, RPM: 1500 RPM, Assets: 55 KW, Additional Information, Series W22, Assets 55 KW, Construction Type B3 (Foot), Engine Cooling LC411 - Tefc, Efficiency Class IE2, Iec Height H 250Mm, Frame Material Cast Iron, Connection Voltage 400/690 V, Pool Number 4 P, Motor Size Iec 250S/M, Insulation Class F, RPM 1500 RPM, Protection Class IP55, Terminal Box Position Top, Output Shaft Diameter De D 65M6, Length Of The Shaft E 140mm, Pitch Of The Holes, Side View B 311/349mm, Chest Of Axle To 1St Mounting Hole 168mm, Pitch Of The Holes, For View A 406mm
- Construction Type: B3 (Foot)
- Efficiency Class: IE2
- Height H: 250mm
- Motor Size: Iec 250S/M
- Series: W22
- RPM: 1500 RPM
- Assets: 55 KW
- Additional Information
- Series W22
- Assets 55 KW
- Construction Type B3 (Foot)
- Engine Cooling LC411 - Tefc
- Efficiency Class IE2
- Iec Height H 250Mm
- Frame Material Cast Iron
- Connection Voltage 400/690 V
- Pool Number 4 P
- Motor Size Iec 250S/M
- Insulation Class F
- RPM 1500 RPM
- Protection Class IP55
- Terminal Box Position Top
- Output Shaft Diameter De D 65M6
- Length Of The Shaft E 140mm
- Pitch Of The Holes, Side View B 311/349mm
- Chest Of Axle To 1St Mounting Hole 168mm
- Pitch Of The Holes, For View A 406mm
W22 IE2 GY 250S/M-04 55KW 4p B3T WEG
This item, manufactured by WEG, is a powerful 55KW 4p B3T electric motor. It is suitable for various industrial applications, including but not limited to manufacturing, processing, and automation. This item can be purchased at PLC2Day, a reliable supplier of industrial automation products.
More Information
| Item Number | W22 IE2 GY 250S/M-04 55KW 4p B3T |
|---|---|
| Brands | WEG |
| HS Code | Upon Request |
| EAN | 0 |
| HS Description | 55KW 3-Phase Motor |
| Manufacturer | WEG |
| Product Condition | Factory New |
| Packing Condition | PLC2Day Packing |
