Telemecanique OsiSense XC Standard Limit Switch

Description

The XCKN2110P20 is a standard format limit switch from Telemecanique, a brand of Schneider Electric. It is designed for detecting the position of moving parts in industrial machinery. This model features a durable plastic housing, a spring return roller plunger, and provides reliable performance in a compact form factor.

Specifications

• Manufacturer: Telemecanique (Schneider Electric)
• Model: XCKN2110P20
• Series: OsiSense XC
• Body Type: Fixed
• Actuator Type: Spring return roller plunger, thermoplastic
• Contact Type: Snap action
• Contact Configuration: 1 NO + 1 NC
• Rated Operational Current (AC-15): 3A at 240V
• Conventional thermal current (Ith): 10A
• IP Protection Rating: IP65
• Connection: M20 x 1.5 cable gland

Label Info

• Standards: EN/IEC 60947-5-1, EN50047
• Ui: 500V
• Uimp: 6kV

Application

Ideal for use in packaging, material handling, conveying, machine tools, and food and beverage applications where reliable position sensing is critical.

Country of Origin

Made in Indonesia.

CO2 Impact

Reusing this component saves approximately 5.0 kg of CO2, contributing to a more sustainable operation by avoiding the production of a new part.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

This limit switch uses snap action contacts, which provide a rapid change of state, independent of the actuator speed. It has one normally open (NO) and one normally closed (NC) contact.

It has an IP65 rating, making it dust-tight and protected against low-pressure water jets. However, the UL listing specifies 'Type 4X indoor use only', so its suitability for outdoor applications depends on the specific environmental conditions and governing standards in your region.

The switch comes with a pre-installed M20 x 1.5 cable gland, suitable for a range of standard industrial cables, simplifying installation.
