SNR 211.NR.Z Deep Groove Ball Bearing

Description

This SNR 211.NR.Z is a robust single-row deep groove ball bearing designed for high performance and durability. It is ideal for applications requiring the support of both radial and axial loads. The inclusion of a snap ring groove and snap ring simplifies mounting and provides secure axial positioning in the housing, while the single metal shield protects the bearing from contaminants.

Specifications

• Manufacturer: SNR
• Type Number: 211.NR.Z
• Inner Diameter (d): 55 mm
• Outer Diameter (D): 100 mm
• Width (B): 21 mm
• Seal: Z (Single-sided metal shield)
• Features: NR (Snap ring groove with snap ring)
• Material: Bearing Steel

Label Info

• Brand: SNR
• Part Number: 211.NR.Z
• EAN: 3413520078942
• Quantity: 1

Application

Suitable for a wide range of industrial applications, including electric motors, gearboxes, pumps, agricultural machinery, and material handling equipment where reliable performance and easy installation are critical.

Country of Origin

Made in France.

CO2 Impact

By purchasing this pre-owned but new-in-box bearing, you contribute to a circular economy and avoid the emission of approximately 1.24 kg of CO2, which would have been generated during the production of a new one.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

Question?
What does the 'NR' suffix in 211.NR.Z signify?

The 'NR' suffix indicates that the bearing has a snap ring groove machined into the outer ring and is supplied with a corresponding snap ring. This feature allows the bearing to be located axially in a housing bore with a simple snap ring, saving space and simplifying the design.

Question?
What is the purpose of the 'Z' suffix?

The 'Z' suffix denotes that the bearing is equipped with a pressed metal shield on one side. This shield helps to retain lubricant and protect the bearing's interior from larger contaminants, while the other side remains open, typically for lubrication purposes or integration into a sealed assembly.

Question?
Can this bearing be used in a high-speed application?

Yes, deep groove ball bearings are suitable for high-speed operation. However, the limiting speed depends on factors like lubrication, load, and heat dissipation. The 'Z' shield has low friction and is well-suited for high speeds, but always consult the manufacturer's datasheet for specific speed ratings based on your application's conditions.
