SKF FY50TF Flanged Bearing Unit

Description

The SKF FY50TF is a high-quality Y-bearing flanged unit featuring a square, four-bolt cast iron housing. It is designed for simple and reliable mounting in applications with rotating shafts. This unit comes complete with an insert bearing that accommodates initial misalignment, and it is pre-lubricated and sealed for long service life. The grub screw locking mechanism ensures a secure fit on the shaft.

Specifications

• Manufacturer: SKF
• Model: FY50TF
• Shaft Diameter: 50 mm
• Housing: FY 510 M (Cast Iron)
• Bearing Insert: YAR 210-2F
• Number of Mounting Holes: 4
• Locking Type: Grub screw
• Sealing: Integrated seals with flingers

Application

Ideal for use in material handling systems, agricultural machinery, food and beverage processing, and general industrial machinery where a robust and reliable bearing solution is required.

Country of Origin

Made in Italy.

CO2 Impact

Reusing this component saves approximately 5.8 kg of CO2, contributing to a more sustainable operation by avoiding the production of a new part.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

What is the proper tightening torque for the grub screws on the FY50TF?

For the YAR 210-2F bearing insert, the recommended tightening torque for the M10x1 grub screws is approximately 16.5 Nm. It is always best to consult the official SKF technical documentation for the most accurate values.

Yes, the FY50TF is equipped with a grease nipple for relubrication. SKF recommends a high-quality lithium complex soap grease, such as SKF LGWA 2, which is suitable for a wide range of operating conditions.

The primary difference is the housing shape. The FY50TF uses a square four-bolt flange housing (FY series), while the FYJ50TF uses an oval two-bolt flange housing (FYJ series). Both units typically contain the same 50mm insert bearing.
