SKF FY30TF Flanged Bearing Unit

Description

The SKF FY30TF is a high-quality Y-bearing square flanged unit, designed for reliable operation in a wide variety of industrial applications. This unit consists of a robust cast iron housing and a YAR 206-2F insert bearing. It is designed for mounting on a 30mm shaft and is easily secured using two set screws. The integrated sealing system provides excellent protection against contaminants, extending the service life of the bearing. A grease nipple is included for convenient relubrication.

Specifications

• Manufacturer: SKF
• Model: FY30TF
• Shaft Diameter: 30 mm
• Housing Type: 4-Bolt Square Flange
• Housing Material: Cast Iron
• Bearing Insert: YAR 206-2F
• Locking Method: Set screw
• Sealing: Double lip seal with flinger

Label Info

• Brand: SKF
• Housing Marking: FY 506 M
• Bearing Marking: YAR 206-2F
• Complete Unit Designation: FY30TF

Application

This flanged bearing unit is ideal for use in agricultural machinery, material handling equipment, food and beverage processing, packaging lines, and general industrial machinery where a simple and effective bearing arrangement is required.

Country of Origin

The bearing insert is manufactured in Italy.

CO2 Impact

Choosing this pre-owned bearing unit saves approximately 2.2 kg of CO2 compared to manufacturing a new one. This saving is equivalent to the emissions from driving a car for 11 kilometers.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

For the M6x0.75 set screws used in the YAR 206-2F bearing, SKF recommends a tightening torque of 4 N-m.

The standard YAR 206-2F bearing with its NBR seals is suitable for continuous operating temperatures up to 100 deg C (210 deg F). For higher temperatures, a different bearing insert and grease would be required.

SKF recommends using a high-quality lithium complex grease, such as SKF LGWA 2, for general purpose applications. Always ensure the grease is compatible with the existing factory fill.
