SKF 6209-2Z Deep Groove Ball Bearing

Description

The SKF 6209-2Z is a versatile and robust deep groove ball bearing, designed for high performance and longevity. It is suitable for a wide range of applications that involve high rotational speeds and both radial and axial loads. This bearing features metal shields on both sides to protect the raceways from dust and other contaminants, extending its service life.

Specifications

• Manufacturer: SKF
• Type Number: 6209-2Z
• Category: Deep Groove Ball Bearing
• Bore Diameter (d): 45 mm
• Outer Diameter (D): 85 mm
• Width (B): 19 mm
• Seals/Shields: 2Z - Metal shield on both sides
• Material: Bearing Steel

Label Info

• Brand: SKF
• Model: 6209-2Z
• Markings: M41

Application

This bearing is commonly used in electric motors, gearboxes, industrial fans, pumps, agricultural machinery, and various other rotating equipment where reliability is crucial.

Country of Origin

Made in Sweden.

CO2 Impact

Opting for this repurposed bearing over a new one prevents the emission of approximately 0.8 kg of CO2, which is equivalent to driving a car for 4 km. Your choice supports a circular economy and reduces industrial waste.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The '2Z' (or 'ZZ') suffix indicates that the bearing is fitted with a pressed sheet steel shield on both sides. These shields help to retain lubricant and prevent the ingress of contaminants, without making contact with the inner ring.

Yes, SKF 6209-2Z bearings are factory-filled with a specific quantity of high-quality grease, making them lubricated for life in many applications and generally maintenance-free.

Unless otherwise specified (e.g., with a C3 or C4 suffix), a standard SKF 6209-2Z bearing has a 'Normal' (CN) radial internal clearance. This is suitable for most standard operating conditions and mounting fits.
