SKF 22208 E Explorer Spherical Roller Bearing

Description

The SKF 22208 E is a high-quality spherical roller bearing from the Explorer series, engineered for superior performance and durability. It is designed to handle heavy loads and accommodate misalignment between the shaft and housing. This makes it ideal for a wide range of demanding industrial applications.

Specifications

• Manufacturer: SKF
• Part Number: 22208 E
• Series: Explorer
• Type: Spherical Roller Bearing
• Bore Diameter (d): 40 mm
• Outside Diameter (D): 80 mm
• Width (B): 23 mm
• Basic Dynamic Load Rating: 83 kN
• Basic Static Load Rating: 78 kN
• Cage Material: Pressed Steel

Label Info

• Model: 22208 E
• EAN: 7316576651922

Application

This bearing is commonly used in applications such as industrial gearboxes, pumps, fans, conveying systems, and paper processing machinery where high loads and potential shaft deflection are present.

Country of Origin

Made in Great Britain.

CO2 Impact

Opting for this component prevents the emission of approximately 1.06 kg of CO2, which would have been generated during the production of a new one.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

What does the 'E' suffix in 22208 E signify?
The 'E' suffix indicates that the bearing has an optimized internal design. This typically includes enhanced roller profiles and a pressed steel cage, resulting in a higher dynamic load carrying capacity compared to older designs.

Is this SKF Explorer bearing suitable for high-speed applications?
Yes, the SKF Explorer class bearings are designed for improved performance, which includes higher speed capabilities. The robust steel cage is well-suited for speed and vibration, but proper lubrication and precise alignment are critical to achieving maximum performance.

What is the recommended lubrication for the 22208 E?
The appropriate lubrication depends heavily on the specific application's speed, load, and operating temperature. For general purposes, a high-quality multipurpose grease like SKF LGMT 2 is often suitable. Always consult the machine's maintenance manual for specific recommendations.
