Siemens SIMATIC S7-300 Positioning Module

Description

The Siemens FM 356-4 is a specialized function module for the SIMATIC S7-300 PLC series, designed for demanding positioning tasks. This module can control up to four independent axes, making it suitable for applications requiring precise motion control with stepper or servo motors. It operates as an intelligent slave to the S7-300 CPU, handling all time-critical positioning functions autonomously.

Specifications

• Manufacturer: Siemens
• Product Series: SIMATIC S7-300
• Module Type: Function Module, Positioning
• Number of Axes: 4
• Input Voltage: 24V DC
• Current Consumption: 0.7A
• Communication: Via S7-300 backplane bus

Label Info

• Model: FM 356-4
• Part Number (MLFB): 6ES7356-4BM00-0AE0
• Serial Number: SVPL5300257

Application

This module is widely used in automated manufacturing, robotics, packaging machinery, and material handling systems where precise, multi-axis control is essential. Its ability to manage complex motion profiles makes it a key component in sophisticated automation solutions.

Country of Origin

Made in Germany.

CO2 Impact

By purchasing this refurbished module, you are contributing to the circular economy and avoiding approximately 16.0 kg of CO2 emissions that would be generated from manufacturing a new one.

Availability

This is a phase-out product but is available as a tested, refurbished spare part. Ideal for maintaining existing S7-300 installations. Order now from PLC2Day for expert support and fast delivery.

FAQ

The FM 356-4 is configured using the "FM 356-4 Configuration Package" software, which integrates into the SIMATIC STEP 7 environment (classic, not TIA Portal).

Yes, the FM 356-4 is versatile and can control both stepper motor drives (with pulse/direction interface) and servo drives (with analog or pulse/direction interface), making it suitable for a wide range of applications.

No, the SIMATIC S7-300 FM 356-4 is part of the classic SIMATIC world and is programmed and configured using STEP 7 V5.x. For TIA Portal, you would need to use a technology module from the S7-1200 or S7-1500 series.
