SICK deTec4 Prime Safety Light Curtain Sender

Description

The C4P-SA03011A00 is the sender unit from SICK's renowned deTec4 Prime series of safety light curtains. Engineered for high performance and reliability, this sender provides a 300 mm protective field height with a 30 mm resolution, making it ideal for hand and finger protection in automated industrial environments. Its robust design and advanced features ensure compliance with the highest safety standards, including PL e and SIL3.

Specifications

• Manufacturer: SICK
• Part Number: 1220084
• Model: C4P-SA03011A00
• System Part: Sender
• Series: deTec4 Prime
• Resolution: 30 mm
• Protective Field Height: 300 mm
• Scanning Range: 21 m
• Safety Integrity Level: SIL3 (IEC 61508), SILCL3 (EN 62061)
• Performance Level: PL e (EN ISO 13849)

Label Info

• Ident-Nr: 1220084
• Type: C4P-SA03011A00
• Serial: 20102910

Application

This safety light curtain sender is designed for use in a wide range of machine safety applications, including press brakes, assembly lines, robotic cells, and packaging machinery, where operator protection is paramount.

Country of Origin

Made in Germany.

CO2 Impact

By purchasing this reconditioned item, you are helping to prevent the emission of approximately 20.0 kg of CO2, contributing to a more sustainable industrial sector.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The compatible receiver for this sender is the SICK deTec4 Prime model C4P-EA03011A00, part number 1220085. It is crucial to use the matched pair to ensure proper optical synchronization and safety functionality.

The deTec4 Prime series, including this C4P-SA03011A00 sender, is designed for direct integration. It features integrated functions like muting, override, and EDM (External Device Monitoring) which can often eliminate the need for an external safety relay or controller, simplifying the wiring and reducing costs.

A 30 mm resolution means the light curtain can reliably detect an object, such as a hand, that is 30 mm in diameter or larger. This is a common specification for hand protection applications, ensuring the machine is stopped before an operator's hand can reach the hazardous area.
