SEW-EURODRIVE 0.75 kW MOVIMOT Geared Motor

Description

This is a complete decentralized drive solution from SEW-EURODRIVE, part of their renowned MOVIMOT series. The unit integrates a 0.75 kW DT80K4 asynchronous motor with a robust gearbox and a frequency inverter, allowing for precise speed control without a separate control cabinet. This specific assembly includes the MLU11A 24V supply module, ensuring the control logic remains powered independently from the main motor supply. It is ideal for conveyor systems, material handling, and other industrial automation applications where space is at a premium and variable speed is required.

Specifications

• Manufacturer: SEW-EURODRIVE
• Product Family: MOVIMOT
• Motor Type: DT80K4
• Power: 0.75 kW
• Voltage: 380-500 V AC (3-phase)
• Frequency: 50 / 60 Hz
• Speed Range: 290 - 2900 rpm
• Current: 1.90 A
• Protection Class: IP55
• Mounting Position: B3 (Foot Mount)
• Additional Module: MLU11A 24V Supply (Part No. 8225842)

Label Info

• Motor Type: 32 DT80K4/...
• Motor No: 6040 35230.9.01.60001 B3
• Module Type: 24V-Versorgung MLU11A
• Module Part No (Sach.Nr.): 8225842

Application

This geared motor is perfectly suited for decentralized installation in machinery and plant engineering. Common applications include conveyor belts, packaging machines, lifting equipment, and logistics systems that benefit from integrated, variable-speed motor control.

Country of Origin

This unit was manufactured by SEW-EURODRIVE in Sweden.

CO2 Impact

Opting for this pre-owned gearmotor prevents the emission of approximately 110.0 kg of CO2 compared to manufacturing a new one. This saving is comparable to the emissions from a 550 km journey in a typical car.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The MLU11A is a 24V supply unit. It provides a separate power source for the inverter's control electronics, allowing the drive to maintain communication and logic functions even if the main 380-500V power is disconnected. This is useful for diagnostics and maintaining network presence in a controlled shutdown.

No. The DT80K4 motor in this MOVIMOT configuration is specifically designed and wound to operate with the integrated frequency inverter. Attempting to connect it directly to a mains 3-phase supply could damage the motor and the inverter.

The nameplate indicates a "B3" mounting position. This is the standard horizontal foot-mount configuration, where the unit is bolted to a flat base using the feet on the gearbox or motor housing.
