Schneider Electric XB4BW34B5 Illuminated Pushbutton

Description

The XB4BW34B5 is a complete illuminated pushbutton unit from Schneider Electric's Harmony XB4 range. This robust component is designed for industrial applications requiring reliable manual control and clear status indication. It features a 22mm mounting diameter and a chromium-plated metal bezel for durability. The flush red pushbutton is spring-return operated and includes an integrated universal LED for illumination.

Specifications

• Manufacturer: Schneider Electric
• Series: Harmony XB4
• Type Number: XB4BW34B5
• Product Type: Illuminated Pushbutton
• Mounting Diameter: 22 mm
• Operator Head: Flush, Red, Unmarked
• Light Source: Protected LED, Universal
• Rated Voltage: 24V AC/DC
• Contact Configuration: 1 NO + 1 NC
• Terminals: Screw clamp terminals
• Bezel Material: Chromium plated metal

Label Info

• EAN: 3389110892055
• Date Code: 3L-2017-12-08

Application

Ideal for use in control panels for manufacturing lines, building automation, and machinery control. The combination of pushbutton and indicator light saves panel space and provides an intuitive user interface for operators.

Country of Origin

This product is Made in France.

CO2 Impact

Opting for a refurbished unit like this one avoids approximately 3.44 kg of CO2 emissions compared to manufacturing a new one, contributing to a more sustainable industrial environment.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The operator (front of panel) is rated IP66, IP67, IP69, and IP69K, which ensures excellent protection against dust ingress and high-pressure, high-temperature water jets. The terminals at the back of the panel are rated IP20.

Yes, the Harmony XB4 series is highly modular. You can easily add, remove, or change the ZBE type contact blocks. This unit comes standard with one ZBE-101 (NO) and one ZBE-102 (NC) block, but the configuration can be customized for your specific application.

A 'Protected LED', as indicated by the model number, includes built-in protection against overvoltage, reverse polarity, and short circuits. This offers superior durability and reliability compared to a simple 'direct supply' LED, especially in demanding industrial electrical environments.
