Schneider Electric TSXRKY8EX 8-Slot PLC Extension Rack

Description

The TSXRKY8EX is an 8-slot extension rack for the Schneider Electric TSX Premium series of PLCs. This backplane allows for the expansion of your control system with additional I/O modules. It is a critical component for maintaining or upgrading existing automation infrastructure based on the robust but now obsolete TSX Premium platform. Manufactured in 2003, this unit is in excellent condition and ready for deployment.

Specifications

• Manufacturer: Schneider Electric
• Series: TSX Premium
• Model Number: TSXRKY8EX
• Product Type: 8-Slot Extension Rack
• Number of Slots: 8
• Communication Ports: 2x DB-9
• Year of Manufacture: 2003

Label Info

• SN: 21031311119
• PV: 01
• RL: 01
• DOM: 03-2003

Application

Designed for industrial automation applications requiring system expansion. Ideal for facilities running legacy systems in manufacturing, process control, and infrastructure who need to add functionality without a full system overhaul.

Country of Origin

Made in France.

CO2 Impact

Reusing this component saves approximately 60 kg of CO2, which is equivalent to driving a car 300 km. Choosing refurbished parts is a sustainable choice for your business and the environment.

Availability

This is an obsolete item, but it is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

No, this rack is designed exclusively for the obsolete Schneider TSX Premium series and is not compatible with modules from the newer Modicon M340 or M580 platforms.

A specific TSX C... series extension cable is required, such as the TSXCBY120K, to ensure proper communication and power distribution between the main and extension racks.

The rack address is set using the blue DIP switches located on the front panel. As the orange warning label indicates, each rack in a multi-rack configuration must be assigned a unique address for the system to function correctly.
