• Specifications:
• Main Range: TeSys
• TeSys Deca Product name: TeSys LRD
• TeSys Deca Product or Component Type: Differential thermal overload relay
• TeSys Deca Device short name: LRD
• Relay application: Motor protection
• Product Compatibility: LC1D25, LC1D32, LC1D38
• Network type: DC, AC
• Thermal overload class: Class 10A IEC 60947-4-1
• Thermal protection adjustment range: 16…24 A
• [Ui] rated insulation voltage: Power circuit 600 V CSA, Power circuit 600 V UL, Power circuit 690 V IEC 60947-4-1
• Complementary:
• Network Frequency: 0...400 Hz
• Mounting support: Plate, with specific accessories, Rail, with specific accessories, Under contactor
• Tripping threshold: 1.14 +/- 0.06 Ir IEC 60947-4-1
• Auxiliary contact composition: 1 NO + 1 NC
• [Ith] conventional free air thermal current: 5 A signalling circuit
• Permissible current: 1.5 A 240 V AC-15 signalling circuit, 0.1 A 250 V DC-13 signalling circuit
• [Ue] rated operational voltage: 690 V AC 0...400 Hz power circuit IEC 60947-4-1
• Associated fuse rating: 4 A gG for signalling circuit, 4 A BS for signalling circuit
• Environment:
• Climatic withstand: IACS E10
• IP degree of protection: IP20 conforming to IEC 60529
• Ambient air temperature for operation: -4…140 °F (-20…60 °C) without derating IEC 60947-4-1
• Ambient Air Temperature for Storage: -76…158 °F (-60…70 °C)
• Flame retardance: V1 conforming to UL 94
• Mechanical robustness: Vibrations6 Gn IEC 60068-2-6, Shocks15 Gn for 11 ms IEC 60068-2-7
• Dielectric strength: 1.89 kV 50 Hz IEC 60947-1
• Standards:
• EN/IEC 60947-4-1, EN/IEC 60947-5-1, UL 60947-4-1, UL 60947-5-1, CSA C22.2 No 60947-4-1, CSA C22.2 No 60947-5-1, GB/T 14048.4, GB/T 14048.5, EN 50495
• Product Certifications:
• IEC, UL, CSA, CCC, EAC, BV, RINA, DNV-GL, LROS (Lloyds register of shipping), ATEX INERIS, UKCA

Schneider Electric LRD22 034684 is a reliable and high-quality industrial item. It is commonly used in various industrial applications such as motor protection. This item can be purchased at PLC2Day.
