Schneider Electric LC1F115M7 TeSys F Contactor with Auxiliary Block

Description

This is a Schneider Electric TeSys F 3-pole contactor, model LC1F115M7. It is designed for high-performance motor control and other heavy-duty switching applications. The contactor is rated for 115A (AC-3) and features a control coil voltage of 115V AC. This unit comes pre-fitted with a Schneider Electric LADN40 front-mount auxiliary contact block, adding four normally open (NO) contacts for enhanced control circuit functionality.

Specifications

• Manufacturer: Schneider Electric
• Series: TeSys F
• Model: LC1F115M7
• Coil Voltage: 115V AC 50/60Hz (Coil model: LX1D6M7)
• Rated Operational Current (AC-3): 115A
• Motor Power (AC-3 at 400V): 37 kW
• Conventional Thermal Current (Ith): 125A
• Number of Poles: 3
• Auxiliary Contacts: LADN40 (4 NO)

Label Info

• Ui: 1000V
• Uimp: 8kV
• Standards: IEC/EN 60947, VDE 0660, BS 5424
• UL/CSA Rated: 600V, 110A

Application

Ideal for controlling motors in applications such as pumps, fans, conveyors, compressors, and other industrial machinery. The robust design is suitable for use in automation and distribution panels.

Country of Origin

Made in France.

CO2 Impact

Choosing this pre-owned contactor saves an estimated 100 kg of CO2 compared to manufacturing a new one. This is a sustainable choice for your operations.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

What is the AC-3 rating of the LC1F115M7?
The AC-3 rating, which is specifically for switching squirrel-cage motors, is 115 Amperes.

Can the LX1D6M7 coil be replaced with a different voltage coil?
Yes, the coil in TeSys F contactors is modular and can be replaced. You can swap the existing 115V AC coil for another LX1D6 series coil that matches your required control voltage.

What is the purpose of the included LADN40 auxiliary contact block?
The LADN40 auxiliary block adds four extra Normally Open (NO) contacts to the contactor. These are typically used for signaling, interlocking, and status indication within the control circuit.
