Schneider Electric iC60H Miniature Circuit Breaker

Description

The A9F84202 from Schneider Electric is a high-performance miniature circuit breaker (MCB) belonging to the renowned Acti9 iC60H series. This 2-pole device is rated for 2 Amperes with a C-type tripping characteristic, making it ideal for protecting circuits against overloads and short circuits in demanding industrial and commercial environments. Its high breaking capacity ensures reliable operation and enhanced installation safety.

Specifications

• Manufacturer: Schneider Electric
• Product Range: Acti9
• Model: iC60H
• Part Number: A9F84202
• Poles: 2P (2-Pole)
• Rated Current: 2 A
• Tripping Curve: C
• Rated Voltage: up to 400V AC
• Breaking Capacity: 10 kA Icu
• Mounting: DIN Rail

Label Info

• Schneider Electric iC60H C2A
• IEC/EN 60947-2, IEC/EN 60898-1

Application

This MCB is suitable for final distribution circuits in commercial buildings, industrial facilities, and data centers. It is commonly used for the protection of lighting circuits, socket outlets, and other loads with moderate inrush currents.

Country of Origin

This product is Made in India.

CO2 Impact

Opting for a refurbished component like this one helps save approximately 10.0 kg of CO2, which is comparable to the emissions from driving a car for 50 kilometers. Your choice supports a more sustainable industrial sector.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

Question?
What is the significance of the "C" curve on this iC60H breaker?

Answer

The "C" tripping curve indicates that the breaker will trip magnetically between 5 and 10 times its rated current (2A). This makes it suitable for general-purpose applications with devices that have a moderate inrush current upon startup, such as lighting systems or standard motors, without causing nuisance tripping.

Question?
Can this MCB be used for both AC and DC applications?

Answer

Yes, while primarily designed for AC systems, the iC60H series is also rated for use in DC circuits. However, the breaking capacity and voltage ratings for DC operation are different from AC ratings. Always consult the official Schneider Electric datasheet for the specific DC performance characteristics before installation.

Question?
What is the breaking capacity of this A9F84202 model and why is it important?

Answer

This iC60H model has a breaking capacity of 10 kA (kiloamperes). This is the maximum short-circuit current that the breaker can safely interrupt without being damaged. A higher breaking capacity, like 10 kA, is crucial for industrial and commercial installations where the potential fault currents are higher, ensuring the safety of the installation and personnel.
