Schneider Electric TeSys GV2ME08 Motor Circuit Breaker

Description

The Schneider Electric GV2ME08 is a high-performance thermal-magnetic motor circuit breaker from the TeSys GV2 product family. It is designed to provide essential protection for three-phase motors against short circuits, overloads, and phase failures. With an adjustable thermal trip setting from 2.5 to 4 Amperes and intuitive push-button control, this device ensures reliable and safe motor operation in a wide range of industrial applications. Its compact design allows for easy integration into control panels.

Specifications

• Manufacturer: Schneider Electric
• Product Range: TeSys GV2
• Model: GV2ME08
• Type: Thermal-Magnetic Motor Circuit Breaker
• Poles: 3-Pole
• Thermal Protection Range: 2.5A to 4A
• Control: Push-button (Start/Stop)
• Rated Operational Voltage (Ue): up to 690V AC 50/60Hz
• Rated Impulse Withstand Voltage (Uimp): 6 kV
• Terminals: Screw Clamp

Label Info

• IEC/EN 60947-2, IEC/EN 60947-4-1
• UL Listed 170M, CSA Certified
• Made in France

Application

Ideal for direct manual control and protection of small motors in applications such as conveyor systems, pumps, fans, and various industrial machinery. It can be used as a standalone manual motor starter or in combination with a contactor for remote control.

Country of Origin

This product is Made in France.

CO2 Impact

By purchasing this reused component, you are helping to avoid the emission of approximately 10.4 kg of CO2. This saving is comparable to the emissions from driving a standard passenger car for 52 kilometers.

Availability

This item is a tested, used product in excellent working condition. It is available for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The thermal protection setting is adjustable from 2.5 Amperes to 4 Amperes, allowing for precise overload protection tailored to your specific motor.

Yes, it is suitable for both 3-phase and 1-phase applications. For single-phase use, the wiring instructions in the manufacturer's datasheet should be followed to ensure proper connection and protection.

The TEST button allows for a manual trip simulation to verify that the tripping mechanism and any associated auxiliary contacts are functioning correctly without an actual overcurrent event.
