Schneider Electric GS1AN22 Auxiliary Contact Block

Description

The GS1AN22 is a high-quality auxiliary contact block manufactured by Schneider Electric, part of their renowned TeSys GS product line. It is designed to be mounted on TeSys GS switch-disconnectors to provide additional signaling and interlocking capabilities. This block features a 2 Normally Open (NO) and 2 Normally Closed (NC) contact configuration, offering versatile feedback for your control systems.

Specifications

• Manufacturer: Schneider Electric
• Type: GS1AN22
• Part Number: 056328
• Product Range: TeSys GS
• Contact Configuration: 2 NO + 2 NC
• Rated Operational Current: 10 A
• Rated Operational Voltage: up to 600V AC / 600V DC
• Utilization Category: A600 / B600

Label Info

• Terminal Tightening Torque: 27 lb-in
• Wire Type: Use 75 deg C minimum copper wire only
• Certifications: CE, cULus, CSA

Application

This auxiliary contact is ideal for industrial applications requiring status feedback from main power switches. It is commonly used in motor control centers, distribution boards, and machine control panels to integrate main disconnects into the broader automation and safety architecture.

Country of Origin

Made in France.

CO2 Impact

By choosing this reused Schneider Electric GS1AN22, you are avoiding approximately 2.8 kg of CO2 emissions. This saving is comparable to the emissions from driving a standard car for 14 kilometers.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The GS1AN22 is specifically designed to be mounted on Schneider Electric's TeSys GS series of switch-disconnectors. It provides electrical feedback about the switch's position (open or closed) to a control system, like a PLC, for monitoring and interlocking purposes.

The terminals are designed for use with copper wire only, rated for a minimum temperature of 75 deg C. The recommended terminal tightening torque is 27 lb-in (approximately 3 Nm) to ensure a secure and reliable connection.

Yes, the GS1AN22 is rated for both AC and DC applications. It has a utilization category of A600 for AC (600VAC) and B600 for DC (600VDC), making it versatile for various industrial control circuits.
