Schneider Electric TeSys D Control Relay

Description

The CAD32E7 from Schneider Electric is a high-performance control relay from the renowned TeSys D series. It is designed for switching control circuits in industrial automation systems, offering reliability and a long mechanical life. This model features a 48V AC coil and a flexible contact arrangement of 3 normally open and 2 normally closed contacts, making it suitable for a wide range of applications including motor control and signaling.

Specifications

• Manufacturer: Schneider Electric
• Type: CAD32E7
• Part Number: 040028
• Product Series: TeSys D
• Description: Control Relay / Auxiliary Contactor
• Coil Voltage: 48V AC (50/60 Hz)
• Contact Configuration: 3 Normally Open (NO), 2 Normally Closed (NC)
• Thermal Current (Ith): 10 A
• Connections: Screw Clamp Terminals

Label Info

• Model: CAD32E7
• EAN: 3389110400281
• Batch Code: 2F 1544

Application

Ideal for use in industrial control panels, motor starters, automation systems, and for general purpose signaling and interlocking circuits where dependable switching is critical.

Country of Origin

Made in France.

CO2 Impact

Opting for this component helps avoid approximately 14.4 kg of CO2 emissions compared to manufacturing a new one. This saving is comparable to the emissions from driving a car for 72 kilometers.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

Question?
What is the conventional free air thermal current (Ith) for the CAD32E7?
Answer:
The CAD32E7 has a conventional free air thermal current (Ith) of 10 A for ambient temperatures up to 60 deg C.

Question?
Can additional auxiliary contact blocks be mounted on this relay?
Answer:
Yes, the TeSys D series, including the CAD32E7, is designed to be modular. You can add front or side-mounted auxiliary contact blocks to expand its switching capacity.

Question?
What type of terminal connections does this relay use?
Answer:
This model uses screw clamp terminals, which provide a secure and reliable connection for control wiring.
