Schneider Electric C60N 1A Miniature Circuit Breaker

Description

This is a C60N miniature circuit breaker (MCB) from Schneider Electric's reliable Multi9 series, part number 24183. It is a 1P+N device with a 1 Ampere C-curve characteristic, designed for DIN rail mounting in commercial and industrial electrical panels. It provides essential protection against both overloads and short-circuits.

Specifications

• Manufacturer: Schneider Electric
• Part Number: 24183
• Series: Multi9 C60N
• Rated Current: 1 A
• Tripping Curve: C
• Poles: 1P+N (2-pole, 1 protected)
• Rated Voltage: 230V AC
• Breaking Capacity: 6kA (IEC 60898-1), 10kA (IEC 60947-2)
• Mounting: DIN Rail

Label Info

• Model: C60N
• Rating: C1 (1 Ampere)
• Part Ref: 24183
• EAN: 3303430241836

Application

Ideal for protecting control circuits, lighting circuits, and other low-current applications in industrial automation, building management, and switchgear panels where reliable overcurrent protection is required.

Country of Origin

Manufactured in France.

CO2 Impact

By purchasing this reused item, you are helping to avoid approximately 8 kg of CO2 emissions. This saving is comparable to the energy needed to drive a standard car for 40 kilometers.

Availability

This is an obsolete item but available from stock. The modern equivalent is from the Schneider Electric Acti9 iC60N series, such as part number A9F04201. Order now from PLC2Day for expert support and fast delivery.

FAQ

The '6000' (6kA) rating corresponds to the IEC/EN 60898-1 standard for domestic or similar installations, while the '10kA' rating corresponds to the more stringent IEC/EN 60947-2 standard for industrial applications. This breaker is certified for both environments.

The 'C' curve is a general-purpose tripping characteristic. It means the breaker will trip magnetically between 5 and 10 times the rated current (5A to 10A). This makes it suitable for a wide range of loads, including lighting, outlets, and small motors with moderate inrush currents.

This 1P+N (1 Pole + Neutral) breaker provides overcurrent protection on the phase (live) pole only. The neutral pole is switched but not protected. It is designed for single-phase circuits where only the live conductor needs protection, but disconnecting the neutral is also required for isolation.
