Schneider Electric Acti9 6A MCB

Description

The A9N21174 is a DIN-rail mounted Miniature Circuit Breaker (MCB) from Schneider Electric's Acti9 series. This 1P+N device offers robust protection for single-phase electrical circuits against overloads and short circuits. With a 6A rating and a C-type tripping curve, it is ideal for a wide range of general-purpose applications.

Specifications

• Manufacturer: Schneider Electric
• Product Series: Acti9
• Part Number: A9N21174
• Poles: 1 Pole + Neutral (1P+N)
• Rated Current: 6A
• Rated Voltage (Ue): 230V AC
• Tripping Curve: C
• Breaking Capacity (Icn): 4500A at 230V AC (acc. to IEC 60898-1)
• Breaking Capacity (Icu): 6kA at 230V AC (acc. to IEC 60947-2)
• Mounting: DIN Rail

Label Info

• Brand: Schneider Electric
• Model: DPN N C6
• Part Nr: A9N21174
• EAN: 3606481381316

Application

This MCB is perfectly suited for protecting lighting circuits, socket outlets, and other loads in residential, commercial, and light industrial settings where reliable overcurrent protection is required.

Country of Origin

Made in France.

CO2 Impact

Opting for a refurbished component like this one saves approximately 4.8 kg of CO2, which is comparable to the emissions from driving a car for 24 km. Your choice supports a more sustainable industrial sector.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

Question?
What is the difference between the Icn and Icu breaking capacity ratings on the A9N21174?

Icn (rated short-circuit breaking capacity) is defined by the IEC/EN 60898-1 standard for residential applications and is 4500A for this device. Icu (ultimate short-circuit breaking capacity) is defined by IEC/EN 60947-2 for industrial applications and is higher at 6kA, indicating its robustness in more demanding environments.

No, this is a 1P+N (single pole + neutral) device designed specifically for single-phase circuits that include a neutral wire. Both the phase and neutral must be connected for it to function correctly and provide proper circuit isolation. The overcurrent protection is only on the phase pole.

The 'C' refers to the tripping curve of the breaker. A C-curve is a general-purpose curve suitable for most applications, like resistive and inductive loads (e.g., lighting, sockets). It is designed to trip magnetically between 5 and 10 times the rated current (In), which helps avoid nuisance tripping from motor start-up inrush currents while still providing effective protection.
