Rexroth R180635131 Guide Rail Connector

Description

The Rexroth R180635131 is a high-quality steel connecting piece designed for joining two SNS Ball Guide Rails of size 35. This component ensures a precise, rigid, and continuous connection, which is essential for maintaining accuracy and stability in long-travel linear motion systems. Manufactured by Bosch Rexroth, it guarantees compatibility and performance within their Ball Rail Systems.

Specifications

• Manufacturer: Bosch Rexroth
• Part Number: R180635131
• Product Type: Guide Rail Connector / Connecting Piece
• Compatible Rail Size: 35
• System: Ball Rail System
• Material: Steel

Label Info

• MNR: R180635131
• Description: R.GUIDE RAIL CS
• Model Code: RSA-035-SNS-S
• Customer P/N: 514224510

Application

This connector is used in various industrial applications where long guide rails are required, such as in large CNC machines, automated assembly lines, material handling equipment, and packaging machinery. It allows for the construction of extended linear axes without compromising on structural integrity or precision.

Country of Origin

Made in Germany.

CO2 Impact

By purchasing this pre-owned component, you are contributing to a circular economy and preventing the emission of approximately 1.0 kg of CO2, which would have been generated during the production of a new part. This saving is equivalent to the CO2 absorbed by a tree in over a month.

Availability

This item is in stock and ready for immediate dispatch. It is new old stock (NOS), in its original sealed packaging. Order now from PLC2Day for expert support and fast delivery.

FAQ

How do I ensure proper alignment when using the R180635131 connector?

Answer: For optimal alignment, it is crucial to use a straightedge or an alignment tool across the joint on the reference side of the rails. Ensure both rail ends are perfectly flush and clean before tightening the mounting screws to the manufacturer's recommended torque specifications.

Is this connector compatible with all Rexroth size 35 guide rails?

Answer: This connector is specifically designed for the SNS (Slimline, Normal, Standard) series of Rexroth Ball Guide Rails in size 35. While it may physically fit other series, using it with non-specified rail types can compromise performance and accuracy. Always verify compatibility with your rail's specific part number.

What is the material of this connector and does it require special maintenance?

Answer: The R180635131 is made from high-strength steel. It does not require specific maintenance itself, but the rail joint area should be kept clean and free of debris. When installing, ensure the area is lightly lubricated as per the overall system's lubrication plan to prevent corrosion.
