ERNI 32-Pin DIN 41612 Female Connector

Description

This is a high-quality 32-pin female connector from ERNI, part number 95425. It conforms to the DIN 41612 / IEC 60603-2 standard, Type C/2. The right-angle design makes it ideal for backplane and board-to-board connections where space is a consideration. Housed in a durable black shroud with mounting ears, it ensures a stable and secure installation.

Specifications

• Manufacturer: ERNI
• Part Number: 95425
• Connector Insert Part Number: 818090
• Standard: DIN 41612 / IEC 60603-2
• Gender: Female (Receptacle)
• Number of Contacts: 32
• Arrangement: 2 rows of 16 contacts
• Termination: Right Angle, for PCB
• Coding: RC2

Label Info

• Sticker: 95425 / PA 149971
• Molded on Connector: V060a18 / ERNI RC2 / 818090

Application

This type of connector is widely used in industrial automation, telecommunications racks, measurement and control systems, and especially in CompactPCI systems for reliable signal and I/O connections.

CO2 Impact

By purchasing this pre-owned component, you are contributing to a circular economy and helping to avoid 0.6 kg of CO2 emissions associated with the production of a new one. This is equivalent to the energy needed for 72 smartphone charges.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

What is the 'RC2' coding on this ERNI connector?

The 'RC2' marking indicates a specific keying or coding feature according to the DIN 41612 standard. This is a mechanical feature on the connector housing that prevents mismating by ensuring it can only be connected to a male counterpart with the corresponding RC2 coding.

Is this connector compatible with the CompactPCI standard?

Yes, the ERNI ERMET series, to which this connector belongs, is designed for use in CompactPCI systems. This 32-pin Type C/2 connector is a standard component used for I/O and user-defined connections on the rear of CompactPCI backplanes.

What is the current rating per pin for this DIN 41612 connector?

According to the ERNI datasheet for standard DIN 41612 connectors like the 818090, the current carrying capacity is typically 1.5 A per contact at 20 deg Celsius. This can vary depending on ambient temperature and the number of loaded contacts, so it is important to consult the full datasheet for derating curves in your specific application.
