Pilz 95425 Connection Plug for PSSuniversal System

Description

This is the Pilz 95425, a robust connection plug specifically designed for the PSSuniversal (PSSu) decentralized I/O system. It provides a secure and reliable interface for connecting field devices. Featuring spring-loaded terminals, it allows for quick, tool-free wiring, reducing installation time and ensuring a vibration-resistant connection. This plug is an essential component for system assembly, maintenance, or expansion.

Specifications

• Manufacturer: Pilz
• Part Number (ID): 95425
• Model: PSSu BP-C 2/2 S
• Product Type: Connection Plug
• System Compatibility: Pilz PSSuniversal
• Connection Type: 2x2-row Spring-loaded terminal
• Nominal Voltage: Dependent on connected I/O module
• Wire Cross-section: 0.25 sq mm to 1.5 sq mm

Label Info

• Pilz P/N: 95425
• Component P/N: ERNI R232a23

Application

The 95425 connector is used across various industries, including automotive, packaging, and general machine building, wherever the Pilz PSSu modular I/O system is implemented for safety and automation tasks. It connects sensors, actuators, and other peripheral devices to the corresponding PSSu modules.

Country of Origin

This product is manufactured by Pilz in Germany.

CO2 Impact

Choosing this reused Pilz connector plug over a new one prevents the emission of approximately 1.0 kg of CO2. This saving is comparable to the emissions from a 5-kilometer car journey.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

This connection plug is designed for use with various modules in the Pilz PSSuniversal series, particularly for I/O modules that require a 2x2-row spring-loaded terminal connection. Always verify the specific module's datasheet to ensure compatibility.

For Pilz spring-loaded terminals of this type, a typical wire cross-section is between 0.25 sq mm and 1.5 sq mm (AWG 24-16). The recommended stripping length is usually around 8-10 mm. Using a suitable tool to open the spring clamp is advised for proper installation.

Yes, this connector is a standard component for the PSSuniversal system, which is frequently used in safety-related applications up to SIL 3 and PL e. The connector itself does not have a safety rating, but its proper installation on a rated PSSu module is critical for the overall system's integrity.
