Pepperl+Fuchs IQT1-F61-IO-V1 Inductive Read/Write Head

Description

The Pepperl+Fuchs IQT1-F61-IO-V1 is a high-performance inductive read/write head designed for industrial identification systems (RFID). It facilitates reliable detection and data exchange with passive transponders. Featuring a standard IO-Link interface, this device offers easy integration into modern automation architectures, providing both event-driven and cyclical data transfer. Its compact and robust F61 housing ensures durability in demanding industrial environments.

Specifications

• Model: IQT1-F61-IO-V1
• Part Number: 299928
• Type: Inductive Read/Write Head
• Interface: IO-Link V1.1
• Sensing Range: 0 to 55 mm
• Operating Frequency: 125 kHz
• Connection: M12 Connector, 4-pin
• Housing: Rectangular, F61
• Degree of Protection: IP67
• Operating Voltage: 18 to 30V DC

Label Info

• Manufacturer: Pepperl+Fuchs
• Type: IQT1-F61-IO-V1
• Part No.: 299928
• Ser.No.: 40000097441791

Application

This read/write head is ideal for applications in factory automation, material handling, and logistics. Common uses include tracking products on conveyor belts, identifying tool carriers in machine building, and managing assets in automated storage and retrieval systems.

Country of Origin

Made in Singapore.

CO2 Impact

By purchasing this component, you are contributing to a circular economy and have helped avoid approximately 4.0 kg of CO2 emissions, which is comparable to the amount produced by driving a standard car for 20 kilometers.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The effective sensing range is from 0 to 55 mm, depending on the transponder type and orientation.

Yes, as it conforms to the IO-Link V1.1 specification, it is compatible with any standard IO-Link master from any manufacturer.

Absolutely. The IQT1-F61-IO-V1 has an IP67 protection rating, meaning it is fully protected against dust ingress and can withstand temporary immersion in water.
