Parker Legris 0103 06 10 Brass Male Branch Tee

Description

This is a high-quality brass male branch tee, part number 0103 06 10, from Parker Legris. It is designed for creating a T-junction from a 6mm outer diameter tube to a G 1/8 inch female threaded port. The compression-style connection ensures a secure and leak-proof seal, suitable for various pneumatic, hydraulic, and fluid transfer applications.

Specifications

• Manufacturer: Parker Legris
• Part Number: 0103 06 10
• Type: Male Branch Tee
• Material: Brass
• Tube Connection: Compression fitting for 6 mm OD tube
• Thread Connection: Male G 1/8 inch BSPP

Label Info

• Item: 06013038
• Description: LEGRIS T-INSCHROEFKOPPELING TIK 6 X 1/8
• PO: 01030610

Application

Ideal for use in industrial automation, machine building, and maintenance applications where reliable connections for air, water, or oil lines are critical. Its robust brass construction ensures durability in demanding environments.

Country of Origin

This product is manufactured in France.

CO2 Impact

Opting for this reused component prevents the emission of approximately 0.1 kg of CO2, which is equivalent to the energy needed for 12 smartphone charges.

Availability

This item is in stock and available for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

What type of tubing is compatible with this Parker Legris 0103 06 10 fitting?

This brass compression fitting is designed for use with a variety of semi-rigid or rigid tubing materials, including copper, brass, steel, aluminum, and hard plastics like polyamide (PA) and polyurethane (PU), as long as the outside diameter is precisely 6 mm.

The Parker Legris 0103 series typically features a British Standard Pipe Parallel (BSPP) thread, often designated with a 'G'. This requires a sealing washer or O-ring on a flat surface for a proper seal, unlike a tapered thread which seals on the threads themselves.

The maximum working pressure is highly dependent on the tube material being used. For example, with soft copper or polyamide tubing at 20 deg. C, the pressure rating can be up to several dozen bar, but this derates significantly with increasing temperature. Always consult the official Parker Legris technical datasheet for the specific tube material and operating temperature to ensure safe operation.
