Parker 6mm Equal Elbow Pneumatic Fitting

Description

This Parker Legris 3538 06 10 is a high-quality, equal elbow push-in fitting from the renowned LF 3000 series. It is designed to provide fast, reliable, and leak-free connections for 6mm OD pneumatic tubing. Its compact design and technopolymer body make it ideal for use in a wide variety of industrial automation applications where space is limited and performance is critical. This listing is for a box of 10 fittings.

Specifications

• Brand: Parker Legris
• Type: Equal Elbow Push-in Fitting
• Model: 3538 06 10
• Tube Outer Diameter: 6 mm
• Body Material: Technopolymer (Plastic)
• Maximum Operating Pressure: 20 bar (290 psi)
• Operating Temperature Range: -20 deg C to +80 deg C
• Fluid Compatibility: Compressed Air, Vacuum

Label Info

• Manufacturer: Parker
• Part Number: 3538 06 10
• Quantity: 10 pieces per box

Application

Perfect for creating 90-degree connections in pneumatic circuits for robotics, packaging machinery, textile manufacturing, and general industrial automation.

Country of Origin

Made in France.

CO2 Impact

Choosing sustainable options matters. By purchasing this product, you help avoid the emission of 0.3 kg of CO2, which is equivalent to charging a smartphone 36 times. This choice supports a circular economy and reduces industrial waste.

Availability

In stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

This fitting is designed for use with semi-rigid tubing such as polyamide (PA), polyurethane (PU), fluoropolymer (FEP), and Teflon (PTFE) tubing with a 6mm outside diameter.

The Parker 3538 06 10 is rated for a maximum operating pressure of 20 bar and can operate in temperatures ranging from -20 deg C to +80 deg C.

Yes, the Parker LF 3000 series fittings are engineered to perform excellently in vacuum applications, holding a vacuum level down to 755 mm Hg (99% vacuum).
