NSK 305805 C/2RS1 Double Row Angular Contact Ball Bearing

Description

This is a high-quality double row angular contact ball bearing, model 305805 C/2RS1, from leading manufacturer NSK. Engineered for high precision and durability, it is designed to accommodate both radial and axial loads in both directions. This bearing is particularly well-suited for applications where rigid guidance of a shaft is required. The integrated seals on both sides provide excellent protection against contaminants, ensuring a long and reliable service life.

Specifications

• Manufacturer: NSK
• Type Number: 305805 C/2RS1
• Type: Double Row Angular Contact Ball Bearing
• Inner Diameter: 25 mm
• Outer Diameter: 47 mm
• Width: 25 mm
• Seals: 2RS1 (Contact seal on both sides)
• Cage Material: TNG (Polyamide)

Label Info

• Box Marking: 305805 C/2RS1
• Bearing Marking: NSK LB3205B2RSRTNG

Application

Commonly used in automotive alternators, small machinery, pumps, and other applications that require robust load support and reliable operation.

Country of Origin

Made in Germany.

CO2 Impact

By purchasing this pre-owned bearing, you are contributing to a circular economy and helping to avoid 0.34 kg of CO2 emissions compared to a new production. This is equivalent to driving 1.7 kilometers in a standard car.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The '2RS1' suffix indicates that the bearing is equipped with contact seals on both sides. These seals are typically made of sheet steel reinforced NBR (nitrile butadiene rubber) and provide excellent protection against the ingress of dust, dirt, and moisture, while also retaining the lubricant within the bearing.

Yes, NSK bearings with the 2RS1 suffix are supplied greased for life. They are pre-filled with a high-quality lubricant suitable for a wide range of operating conditions and do not require any additional lubrication before or during their service life.

The 'TNG' marking specifies the material and design of the bearing cage. In this case, it refers to a snap-type cage made from glass-fibre reinforced polyamide 66. This material offers a favorable combination of strength and elasticity, low friction, and is suitable for high-speed operation.
