NSK 23028CDKE4C3S11 Spherical Roller Bearing

Description

The NSK 23028CDKE4C3S11 is a premium spherical roller bearing designed for heavy-duty industrial applications. It features a double row of symmetrical rollers, which allows it to self-align and handle significant shaft deflection and misalignment. This bearing is engineered to accommodate very heavy radial and axial loads in both directions, ensuring robust performance under the toughest conditions.

Specifications

• Bore Diameter (d): 140 mm
• Outer Diameter (D): 210 mm
• Width (B): 53 mm
• Bore Type: Tapered (K), taper 1:12
• Cage Material: Pressed Steel (CD)
• Internal Clearance: C3 (Greater than Normal)
• Special Treatment: S11 (Heat stabilized for temperatures up to 200 deg C)
• Lubrication: E4 (Outer ring with lubrication groove and holes)

Label Info

• Brand: NSK
• Model: 23028CDKE4C3S11
• Origin: Made in Japan

Application

This bearing is ideal for use in equipment such as vibrating screens, conveyors, gearboxes, paper machines, and other heavy machinery where high loads and misalignment are common.

Country of Origin

This product is manufactured by NSK in Japan.

CO2 Impact

Opting for this component saves approximately 12.5 kg of CO2 emissions compared to manufacturing a new one, contributing to a more sustainable industrial operation.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The 'K' suffix indicates that the bearing has a tapered bore, typically with a 1:12 taper. This design allows for easy mounting and dismounting using an adapter sleeve or withdrawal sleeve on a cylindrical shaft.

C3 is an internal radial clearance that is greater than the 'Normal' clearance. It is used in applications where there may be a tight fit on the shaft or in the housing, or where a temperature differential between the inner and outer rings could reduce operational clearance.

The S11 suffix means the bearing rings are heat-stabilized for operation at temperatures up to 200 deg Celsius. It is critical to use a compatible high-temperature grease to ensure proper lubrication and achieve the expected service life in such conditions.
