Legrand DX3 4202 08 Miniature Circuit Breaker

Description

The Legrand 4202 08 is a DIN rail mountable Miniature Circuit Breaker (MCB) from the DX3 series. This device provides essential overcurrent and short-circuit protection for electrical installations. It features a 1P+N configuration, a rated current of 4A, and a C-type tripping curve, making it ideal for general-purpose applications in commercial and industrial environments.

Specifications

• Manufacturer: Legrand
• Part Number: 4202 08
• Series: DX3
• Rated Current: 4A
• Tripping Curve: C
• Number of Poles: 1P+N
• Rated Voltage: 230V AC
• Frequency: 50/60Hz
• Breaking Capacity (Icu): 6 kA (IEC 60947-2)
• Mounting: DIN Rail

Label Info

• Legrand 4202 08
• C4 / 6000
• IEC 60947-2 Cat. A

Application

This MCB is commonly used in distribution boards to protect final circuits for lighting, sockets, and other general loads against overload and short-circuit faults. The 1P+N design ensures complete isolation of the circuit for maintenance and safety.

Country of Origin

Made in France.

CO2 Impact

By purchasing this reused Legrand MCB, you are contributing to a circular economy and helping to avoid 4.8 kg of CO2 emissions associated with the production of a new unit. This saving is equivalent to the emissions from driving a standard car for approximately 24 kilometers.

Availability

This item is a used, tested product in excellent working condition. It is available for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

What is the difference between a C-curve and a B-curve circuit breaker?

A C-curve breaker, like this Legrand 4202 08, is designed for general purpose applications with moderate inrush currents, like lighting and standard outlets. It trips between 5 and 10 times the rated current. A B-curve breaker is more sensitive, tripping between 3 and 5 times the rated current, and is used for resistive loads with little to no inrush current.

Both ratings refer to the breaker's short-circuit breaking capacity. The '6000' (or 6kA) under the IEC 60898-1 standard is for residential use, while 'Icu=6 kA' (Ultimate Breaking Capacity) under the IEC 60947-2 standard is for industrial applications. It means the device can safely interrupt a fault current of 6000 Amperes without being destroyed.

No, this is a 1P+N (single pole + neutral) breaker. It is specifically designed for single-phase circuits that have both a phase (live) and a neutral conductor. The neutral pole is switched along with the phase pole, providing full isolation. Using it without a neutral would be incorrect and potentially unsafe.
