INA HK3016-2RS Needle Roller Bearing

Description

The INA HK3016-2RS is a high-precision drawn cup needle roller bearing designed for applications requiring high load-carrying capacity and a small radial cross-section. Featuring contact seals on both sides (2RS), this bearing offers excellent protection against contamination and retains grease effectively, extending its operational life. It is an ideal component for compact and cost-effective bearing arrangements.

Specifications

• Manufacturer: INA
• Part Number: HK3016-2RS
• Type: Drawn Cup Needle Roller Bearing
• Bore Diameter (d): 30 mm
• Outer Diameter (D): 37 mm
• Width (B): 16 mm
• Seals: 2RS - Contact seals on both sides
• Material: High-carbon chromium bearing steel

Label Info

• Model: HK3016-2RS
• Suffix: L271
• EAN: 4012802368758

Application

This bearing is commonly used in automotive transmissions, two-stroke engines, gear pumps, and various industrial machinery where space is limited but high radial load capacity is essential.

Country of Origin

Made in Germany.

CO2 Impact

Opting for this reused component prevents the emission of approximately 0.07 kg of CO2, which would have been generated during the production of a new one. This is equivalent to the energy needed to fully charge a smartphone more than 8 times.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

Question?
What does "2RS" signify in the HK3016-2RS part number?

The "2RS" suffix indicates that the bearing is equipped with contact seals made of nitrile butadiene rubber (NBR) on both sides. These seals provide excellent protection against the ingress of dirt and moisture, and they also help to retain the lubricant within the bearing, ensuring a long service life.

Yes, the HK series of drawn cup needle roller bearings is designed to run directly on a hardened and ground shaft. For optimal performance, the shaft raceway must meet specific requirements for surface hardness (typically 60 HRC), roughness, and geometric accuracy. If the shaft cannot be prepared this way, an INA inner ring (IR series) can be used.

Drawn cup needle roller bearings must be installed using a press-fit into the housing bore. It is critical to use a proper mounting mandrel that applies force only to the stamped face of the outer cup. Applying force to the open end or the rolling elements can damage the bearing. The bearing should be pressed in until its face is flush with the housing face.
