IMI Norgren T70C3800 Excelon Plus Pressure Regulator

Description

The T70C3800 is a general purpose pressure regulator from IMI Norgren's renowned Excelon Plus series. It is engineered for robust performance in industrial pneumatic applications, providing accurate and stable pressure regulation. This model features a tamperproof T-bar adjustment mechanism, ensuring that settings remain secure. Its compact and lightweight design allows for easy integration into new or existing air preparation systems.

Specifications

• Manufacturer: IMI Norgren
• Series: Excelon Plus T70
• Model: T70C3800
• Port Size: G3/8 (BSPP)
• Outlet Pressure Range: 0.3 to 8 bar (4 to 116 psi)
• Maximum Inlet Pressure: 20 bar (Polymer Bowl)
• Adjustment Type: Tamperproof T-bar
• Operating Temperature: -34 deg C to +65 deg C
• Flow Rate: Up to 55 dm3/s at 10 bar inlet, 6.3 bar outlet
• Gauge Port: G1/8

Label Info

• Item No: 46CF9002
• Part Number: T70C3800

Application

Ideal for general industrial applications requiring precise control of compressed air. Suitable for use in manufacturing lines, automation equipment, and pneumatic control systems where consistent downstream pressure is critical.

Country of Origin

Made in China.

CO2 Impact

Opting for this component prevents the emission of approximately 2.0 kg of CO2, which is comparable to the carbon footprint of its production and transport. This saving is equivalent to driving a car for 10 km.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The maximum rated inlet pressure for this regulator with its standard polymer construction is 20 bar (290 psi).

Yes, the Excelon Plus series, including the T70C3800, is fully compatible with both lubricated and non-lubricated compressed air systems.

Yes, this regulator is equipped with standard G1/8 gauge ports, allowing you to easily install a compatible pressure gauge if needed.
