IGUS Drylin W Linear Bearing Housing 6mm WJ200QM-01-06

Description

The IGUS WJ200QM-01-06 is a high-quality square linear bearing housing from the Drylin W series. It is engineered for precision linear motion applications on 6mm square guide rails. The housing is made from hard-anodised aluminum for excellent rigidity and corrosion resistance, while the integrated iglidur J200 liner provides a self-lubricating, low-friction, and maintenance-free sliding surface. This makes it an ideal choice for clean environments, automation, and general machine building.

Specifications

• Brand: IGUS
• Model: WJ200QM-01-06
• Series: Drylin W
• Type: Square Linear Bearing Housing
• Shaft Diameter: 6 mm
• Housing Material: Hard-anodised aluminum
• Liner Material: iglidur J200
• Static Load Capacity (C0): 240 N
• Dynamic Load Capacity (C): 120 N

Application

This linear bearing is suitable for a wide range of applications, including 3D printers, CNC machines, laboratory equipment, and automated handling systems where precise, quiet, and lubrication-free movement is required.

Country of Origin

Germany

CO2 Impact

By purchasing this pre-owned component, you are contributing to a circular economy and have helped avoid approximately 0.14 kg of CO2 emissions associated with the production of a new part. This saving is equivalent to charging a smartphone more than 16 times.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

What is the recommended rail type for the WJ200QM-01-06?

This bearing housing is specifically designed for the IGUS Drylin W series 6mm square guide rails, such as the model WSQ-06-30, to ensure optimal performance and fit.

No, the integrated iglidur J200 liner is self-lubricating. This makes the bearing completely maintenance-free and ideal for dry-running applications, especially in environments sensitive to contamination.

According to official IGUS specifications, the maximum dynamic load capacity (C) is 120 N, and the maximum static load capacity (C0) is 240 N. These values are critical for ensuring the longevity and safety of your system design.
