HFB Taconite Seal Set LDZ 509 for Bearing Housings

Description

This is a complete LDZ 509 Taconite seal set manufactured by HFB. Designed for plummer block bearing housings, this seal provides excellent protection against dust, dirt, moisture, and other contaminants. Its robust multi-labyrinth design makes it ideal for use in harsh industrial environments such as mining, agriculture, and steel manufacturing, significantly extending the service life of bearings.

Specifications

• Manufacturer: HFB Waelzlager-Gehaeusetechnik GmbH
• Model: LDZ 509
• Product Type: Taconite Seal Set
• Shaft Diameter: 45 mm
• Compatible Housing Series: 509
• Seal Material: NBR (Nitrile Butadiene Rubber)
• Design: Multi-stage labyrinth with integrated V-ring

Label Info

• Brand: HFB Sealing
• Type: LDZ 509
• Quantity: 1 set

Application

Specifically designed for sealing plummer block bearing housings on 45mm shafts. Commonly used in conveyor systems, industrial fans, and processing machinery where reliable sealing is critical.

Country of Origin

Germany

CO2 Impact

By reusing this component, you contribute to a circular economy and avoid the production of a new one, saving an estimated 1.0 kg of CO2. This is comparable to the emissions from a 5 km car journey.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

A Taconite seal offers a much higher level of protection. It creates a complex, grease-filled path (a labyrinth) that makes it extremely difficult for contaminants to reach the bearing, making it superior for dusty and wet environments where simpler seals would fail.

Labyrinth seals like the LDZ 509 are generally excellent for high-speed applications because they are non-contact seals, meaning there is no friction or heat generation from the seal lip rubbing on the shaft, which can be a limiting factor for contact seals.

It is recommended to use a grease compatible with the bearing grease, typically a lithium-based NLGI 2 or 3 grease. The grease acts as an additional barrier against contamination and should be periodically purged and replenished via the grease nipple on the housing.
