HAHN Hydraulik HCDH2 Series Hydraulic Cylinder

Description

This is a HAHN Hydraulik tie-rod cylinder, model HCDH2, designed for high-pressure hydraulic systems. With a robust construction and precision engineering, this cylinder provides reliable and powerful linear actuation for a wide range of industrial machinery. This specific unit, manufactured in 2017, is new old stock and in excellent condition, ready for immediate deployment.

Specifications

• Manufacturer: HAHN Hydraulik
• Series: HCDH2
• Piston Diameter (Bore): 80 mm
• Rod Diameter: 56 mm
• Stroke Length: 200 mm
• Maximum Operating Pressure: 250 bar
• Mounting Type: MP5 - Rear pivot with spherical bearing

Label Info

• Model: HCDH2 MP5/80/56/200 A1X/B2 CFDMEW
• Ident-Nr.: 5284270013
• Zylinder-Nr.: 88322
• Drawing Ref.: ZS-43720-07

Application

Ideal for use in mobile hydraulics, manufacturing equipment, presses, and other heavy-duty applications where precise and powerful force is required.

Country of Origin

Made in Germany.

CO2 Impact

By purchasing this pre-owned cylinder, you are preventing the emission of approximately 50 kg of CO2 associated with the production of a new one. This choice supports a more sustainable industrial ecosystem.

Availability

This item is in stock and ready for worldwide shipping. Order now from PLC2Day for expert support and fast delivery.

FAQ

What is the significance of the mounting type 'MP5' for this cylinder?

The MP5 designation, according to ISO 6020/2, refers to a rear pivot mounting with a spherical bearing. This allows for angular movement and compensates for misalignment during operation, reducing stress on the cylinder and connected structures.

Can this cylinder be used with different hydraulic fluids?

This cylinder is typically designed for standard hydraulic mineral oils (e.g., HLP). For use with other fluids like water-glycol or synthetic esters, you must consult the manufacturer's specifications for seal compatibility to prevent damage and ensure safe operation.

The label mentions drawing number ZS-43720-07. What does this imply for interchangeability?

This indicates the cylinder was custom-built to a specific customer's drawing. While the core dimensions (bore, stroke) are standard, other features like port positions, rod end threads, or cushioning might be non-standard. It is crucial to verify these details against your application's requirements before installation.
