Festo QST-10 10mm Pneumatic Push-in Union T-Connector

Description

This is a set of Festo QST-10 push-in T-connectors, designed for quick and reliable connections in pneumatic systems. The union T-shape allows for splitting a single pneumatic line into two. The convenient push-in fitting system ensures easy installation and maintenance for 10mm OD tubing.

Specifications

• Manufacturer: Festo
• Type: Push-in T-connector, Union T
• Model: QST-10
• Part Number: 153130
• Nominal Size: 7 mm
• Tubing OD: 10 mm
• Operating Pressure: -0.95 to 10 bar
• Operating Medium: Compressed air
• Ambient Temperature: -10 to 80 deg C
• Housing Material: PBT (Polybutylene terephthalate)

Label Info

• Brand on component: Festo
• Part Number on component: Not visible
• Part Number on packaging (assumed): 153130

Application

Ideal for use in a wide range of industrial automation, machine building, and pneumatic control systems where distribution of compressed air is required. Suitable for standard compressed air applications.

Country of Origin

Germany

CO2 Impact

By choosing this pre-owned set of fittings, you help save 4.8 kg of CO2. This is equivalent to the emissions from driving a car for 24 kilometers.

Availability

This set is in stock and ready for immediate dispatch. The components are new (old stock) and unused, supplied in neutral packaging. Order now from PLC2Day for expert support and fast delivery.

FAQ

What types of tubing are compatible with the Festo QST-10 fitting?
The QST-10 is designed for use with pneumatic plastic tubing (OD 10mm) made from materials like Polyamide (PA), Polyurethane (PU, PUN), and Polyethylene (PE). Ensure the tube has a clean, right-angle cut for a secure seal.

What is the maximum operating pressure for this fitting?
The QST-10 is rated for a complete temperature range operating pressure of -0.95 to 10 bar. The maximum permissible pressure can also depend on the temperature and the type of tubing used.

Can this QST-10 fitting be used for vacuum applications?
Yes, the QST-10 is suitable for vacuum applications down to -0.95 bar, making it versatile for both pressure and vacuum systems.
