Festo PEM-1/4-WD-LED-24 Pressure Switch

Description

The Festo PEM-1/4-WD-LED-24 is a compact, diaphragm-type pressure switch designed for reliable pressure monitoring in pneumatic systems. It features an adjustable switching point and a clear LED indicator for visual status feedback. This component is ideal for applications requiring precise pressure detection and control. Order now from PLC2Day for expert support and fast delivery.

Specifications

• Manufacturer: Festo
• Type: PEM-1/4-WD-LED-24
• Part Number: 164274
• Operating Medium: Filtered compressed air
• Pneumatic Connection: G1/4
• Switching Function: Normally open contact (NO)
• Switching Output: PNP
• Operating Voltage: 12 to 24V DC
• Pressure switching point: 1 to 12 bar
• Electrical Connection: Plug, DIN EN 175301-803, Form C

Label Info

• Brand: FESTO
• TN: 164274
• Designation: DISTRIB./ACC. PEM-1/4-WD-LED-24

Application

This pressure switch is commonly used in industrial automation, machine building, and material handling systems to monitor system pressure, control actuators, or provide safety signals based on pressure levels.

Country of Origin

This product is manufactured by Festo in Germany.

CO2 Impact

By purchasing this reused component, you are saving an estimated 3.2 kg of CO2, which is comparable to the emissions from driving a car for 16 kilometers. Choosing refurbished parts contributes to a more sustainable industrial environment.

Availability

This is an obsolete item, but it is available from our stock. The modern equivalent recommended by Festo is the PEV-1/4-B-OD (Part no. 161759).

FAQ

Question?

What is the adjustable pressure range for the PEM-1/4-WD-LED-24?

The Festo PEM-1/4-WD-LED-24 has an adjustable pressure switching range of 1 to 12 bar. The pressure is set using an adjustment screw on the device.

Is the PNP output on this pressure switch protected against short circuits?

Yes, the PNP switching output on this model includes short circuit protection, enhancing its durability and reliability in industrial environments.

What type of electrical connector is required for this Festo pressure switch?

This switch uses a plug connector according to DIN EN 175301-803, form C. This is a common connector type for pneumatic valves and sensors, ensuring easy integration.
