Festo MSFW-24-50/60 Solenoid Coil

Description

The Festo MSFW-24-50/60 is a high-quality solenoid coil designed for reliable operation of Festo pneumatic solenoid valves. It operates on a standard 24V AC power supply at either 50Hz or 60Hz, making it versatile for various industrial applications worldwide. When paired with a corresponding plug socket, it achieves an IP65 rating, ensuring protection against dust and water jets.

Specifications

• Manufacturer: Festo
• Type: MSFW-24-50/60
• Part Number: 4534
• Electrical Connection: Per DIN EN 175301-803
• Operating Voltage: 24V AC
• Frequency: 50/60 Hz
• Power Consumption (Inrush): 9 VA
• Power Consumption (Holding): 7 VA
• Duty Cycle: 100%
• Protection Class: IP65 (with correctly installed socket)

Label Info

• Brand: FESTO
• Model: MSFW-24-50/60
• Part Nr: 4534
• Specs: 24V AC 50/60Hz, 9/7VA, IP00/65

Application

This solenoid coil is used to actuate solenoid valves in various pneumatic systems, including factory automation, material handling, process control, and machinery manufacturing. It is compatible with a wide range of Festo valve series.

Country of Origin

This product is manufactured in Germany.

CO2 Impact

Opting for this pre-owned component saves an estimated 2.0 kg of CO2 compared to a new one, contributing to a more sustainable industrial operation.

Availability

This item is in stock and available for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The IP00 rating applies to the coil's bare electrical terminals. The higher IP65 rating is achieved only when the coil is properly connected and sealed with a compatible electrical plug socket, protecting it from dust and low-pressure water jets.

Yes, its dual-frequency rating (50Hz and 60Hz) makes it suitable for use in electrical systems across the globe, including Europe (50Hz) and North America (60Hz), provided the voltage is 24V AC.

The MSFW-24-50/60 is a standard coil compatible with numerous Festo valve families, including but not limited to MFH, MOFH, JMFH, and VUVG series. Always verify compatibility with your specific valve's datasheet.
