Festo DNU-63-160-PPV-A Pneumatic Standard Cylinder

Description

The Festo DNU-63-160-PPV-A is a high-quality, double-acting pneumatic standard cylinder designed for a wide array of industrial automation applications. Built to ISO 6431 and VDMA 24562 standards, it ensures compatibility and interchangeability. This cylinder features adjustable pneumatic cushioning at both ends, which allows for precise control over deceleration, reducing mechanical shock and noise. Its robust construction guarantees a long service life even in demanding environments.

Specifications

• Manufacturer: Festo
• Type: Pneumatic Standard Cylinder
• Model: DNU-63-160-PPV-A
• Part Number: 14160
• Piston Diameter (Bore): 63 mm
• Stroke Length: 160 mm
• Operating Principle: Double-acting
• Cushioning: PPV (Adjustable pneumatic cushioning at both ends)
• Maximum Operating Pressure: 12 bar / 174 psi
• Standard Conformity: ISO 6431, VDMA 24562

Label Info

• Typ: DNU-63-160-PPV-A
• Part No: 14160
• max: 12bar/174psi
• Serie: K608

Application

This cylinder is ideal for linear motion tasks such as positioning, clamping, pressing, and material handling in automated systems, machine building, and process industries.

Country of Origin

Made in Germany.

CO2 Impact

Choosing this used component saves an estimated 25.0 kg of CO2 compared to a new one, contributing to a more sustainable industrial operation.

Availability

This is an obsolete item but is available from our stock. The modern equivalent from Festo is the DSBC series. Order now from PLC2Day for expert support and fast delivery.

FAQ

The 'PPV' in Festo's nomenclature stands for adjustable pneumatic cushioning at both ends of the cylinder. This feature allows you to fine-tune the speed of the piston at the end of its stroke, reducing impact and noise, which extends the life of the cylinder and the machine.

Yes, the DNU series features T-slots on its profile barrel designed for mounting Festo proximity sensors. It is compatible with modern Festo sensor series like the SMT-8M, which can be easily inserted into the slots to detect the piston's position.

As an ISO 6431 standard cylinder, the DNU-63-160-PPV-A supports a wide range of standard mountings. These include foot mounts, flange mounts, and clevis brackets for the rear end, as well as various piston rod attachments like rod eyes and clevises. The cylinder in the image is shown with a rear clevis foot mount attached.
