FAG H322 Adapter Sleeve

Description

The FAG H322 is a high-quality adapter sleeve designed for mounting bearings with a tapered bore onto 100mm cylindrical shafts. As a standard component from a leading manufacturer, it ensures precise and secure positioning, simplifying both installation and removal processes. This sleeve is supplied as a complete set with the corresponding lock nut and locking device.

Specifications

• Manufacturer: FAG (Schaeffler Group)
• Part Number: H322
• Product Type: Adapter Sleeve
• Shaft Diameter: 100 mm
• Material: Steel
• Standard: Conforms to DIN 5415

Application

Adapter sleeves are the most commonly used components for locating bearings with a tapered bore onto a cylindrical shaft seating. They can be used on plain shafts or stepped shafts, allowing for simplified shaft design and reduced machining costs.

Country of Origin

This product is typically manufactured in Germany.

CO2 Impact

Choosing a pre-owned or surplus item like this FAG H322 adapter sleeve avoids the CO2 emissions associated with new production, estimated at 5.9 kg. This saving is a direct contribution to more sustainable industrial operations.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

What type of bearing is the FAG H322 adapter sleeve typically used with?

The H322 adapter sleeve is designed for use with self-aligning ball bearings, spherical roller bearings, and CARB toroidal roller bearings that have a tapered bore, such as those in the 222, 232, 22200, and 23200 series. For this sleeve (100mm shaft), it would be compatible with bearings like 22222-E1 or 23222-E1.

The correct procedure involves using a hook spanner to tighten the lock nut until the specified radial internal clearance reduction is achieved. This ensures the correct interference fit. Refer to the FAG mounting instructions for the specific bearing to find the exact clearance reduction values and drive-up method.

Yes, a standard H series adapter sleeve assembly like the H322 is always supplied complete with the corresponding lock nut and locking washer required for secure installation.
