FAG 6213 Deep Groove Ball Bearing

Description

The FAG 6213 is a single-row deep groove ball bearing, a versatile and widely used component in industrial machinery. Its design allows it to accommodate radial and axial loads in both directions. This open-type bearing is intended for applications where it can be lubricated with oil or grease within the housing, making it ideal for gearboxes and other enclosed systems. Manufactured to high precision standards in Germany, it guarantees reliable performance and durability.

Specifications

• Manufacturer: FAG
• Part Number: 6213 (01992010)
• Type: Deep Groove Ball Bearing
• Inside Diameter (d): 65 mm
• Outside Diameter (D): 120 mm
• Width (B): 23 mm
• Seal Type: Open (no seals)
• Cage Material: Steel
• Static Load Rating: 45000 N
• Dynamic Load Rating: 68500 N

Label Info

• Brand: FAG
• Model: 6213
• Part Nr: 01992010
• EAN: 4012801076609

Application

This bearing is commonly used in electric motors, pumps, gearboxes, conveyors, and general industrial machinery where reliability and high rotational speeds are required.

Country of Origin

Made in Germany.

CO2 Impact

Choosing this reused FAG 6213 bearing over a new one prevents the emission of approximately 2.18 kg of CO2, contributing to a more sustainable industrial operation.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The open design means the bearing has no integrated seals or shields. This makes it ideal for applications within a sealed housing, like a gearbox, where it is lubricated by the system's oil or grease bath. It allows for easier lubrication but offers no protection against external contaminants.

The ideal lubrication method (oil or grease) and interval depend heavily on the operating conditions, including speed, load, and temperature. For high-speed applications, oil-bath or oil-mist lubrication is often preferred. For general use, a high-quality lithium-based grease is suitable. Always consult the machinery's maintenance manual for specific recommendations.

No, this is generally not recommended. A 6213-2RS (rubber seals) or 6213-ZZ (metal shields) is designed for applications where the bearing needs to be protected from contaminants and retain its own grease. Replacing a sealed bearing with an open one would expose the rolling elements to dirt and moisture, leading to premature failure unless the housing itself is perfectly sealed and provides lubrication.
