FAG 222SM125-TVPA Split Spherical Roller Bearing

Description

The FAG 222SM125-TVPA is a split spherical roller bearing with a 125 mm bore diameter. This innovative design allows the bearing to be installed and replaced without requiring the removal of other components from the shaft, significantly reducing downtime and maintenance costs. It is ideal for use in difficult-to-access locations or on long shafts with multiple supports. This bearing is designed for high load-carrying capacity and can accommodate misalignment.

Specifications

• Manufacturer: FAG
• Model: 222SM125-TVPA
• Type: Split Spherical Roller Bearing
• Bore Diameter (d): 125 mm
• Outside Diameter (D): 225 mm
• Width (B): 58 mm
• Cage Material: Glass fibre reinforced polyamide (TVPA)
• Basic Dynamic Load Rating (C): 355 kN
• Basic Static Load Rating (C0): 450 kN

Label Info

• Part Number: 222SM125-TVPA
• EAN: 4012801478830

Application

These bearings are commonly used in conveyor systems, ventilation plants, rolling mills, and marine propulsion systems where maintenance time is critical.

Country of Origin

Made in the USA.

CO2 Impact

By purchasing this refurbished or new-old-stock bearing, you contribute to a circular economy and help avoid 31.2 kg of CO2 emissions associated with the production of a new one.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

What are the main advantages of a split spherical roller bearing like the 222SM125-TVPA?

The primary advantage is ease of installation and maintenance. The bearing can be mounted without disassembling the entire shaft or removing adjacent components like couplings or gearboxes, which dramatically reduces downtime and labor costs.

'TVPA' specifies the cage design and material. It indicates a window-type cage made from glass fibre reinforced polyamide (PA66), which is centered on the rolling elements. This material offers a good balance of strength, elasticity, and low friction.

It is crucial to follow the manufacturer's mounting instructions. The screws must be tightened in a crosswise sequence and in several stages to ensure even clamping pressure. Using a torque wrench to apply the specified final tightening torque is mandatory for secure and proper operation. The included Loctite 243 should also be applied as directed.
