22244BEXLK FAG, Spherical roller bearing (X-life), Specifications, Brand, FAG, Item Number, 22244-BE-XL-K FAG, Manufacturer Part Number, 0659338770000, Also known as, 22244-BE-K, EAN, 4012802504880, Category, Spherical Roller Bearing, Weight and Dimensions, Inner (d) MM, 220, Outer (D) MM, 400, Width (B) MM, 108, Inner (d) Inch, 8.6614, Outer (D) Inch, 15.748, Width (B) Inch, 4.252, Weight (kg), 57.9, Product Properties, Bore, K - 1:12 Tapered Bore (Standard for Most Types), Lubrication Enhancement, W33 - Lubrication Groove and 3 Holes, Seal, No Seal, Cage Type, S - Steel or Standard Cage, Radial Internal Play, Cn Normal Internal Play, Precision, Standard Precision, Heat Stabilization, No Heat Stabilization - Temperatures up to 120 °C, Vibrating Screen Execution, Non Vibrating Screen Execution, Data from Schaeffler (medias), Width (b) mm, 108, Radial Static Load Rating C0r (N), 2360000, Radial Dynamic Load Rating Cr (N), 1840000, Basic static load rating, radial (C 0r), "2360000.0000", Limiting speed (n G), 2140, Reference speed (n ϑr), 1350, ECLASS number, 23-05-09-11, ECLASS2 number, 23-05-09-11, Medias description, Spherical roller bearings 222..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12, Suffix description, BE, Maximum Capacity Design, XL, X-Life, K, Tapered Bore, Taper 1:12

• 22244BEXLK FAG
• Spherical roller bearing (X-life)
• Specifications:
  • Brand: FAG
  • Item Number: 22244-BE-XL-K FAG
  • Manufacturer Part Number: 0659338770000
  • Also known as: 22244-BE-K
  • EAN: 4012802504880
  • Category: Spherical Roller Bearing
  • Weight and Dimensions:
    • Inner (d) MM: 220
    • Outer (D) MM: 400
    • Width (B) MM: 108
    • Inner (d) Inch: 8.6614
    • Outer (D) Inch: 15.748
    • Width (B) Inch: 4.252
    • Weight (kg): 57.9
  • Product Properties:
    • Bore: K - 1:12 Tapered Bore (Standard for Most Types)
    • Lubrication Enhancement: W33 - Lubrication Groove and 3 Holes
    • Seal: No Seal
    • Cage Type: S - Steel or Standard Cage
    • Radial Internal Play: Cn Normal Internal Play
    • Precision: Standard Precision
    • Heat Stabilization: No Heat Stabilization - Temperatures up to 120 °C
    • Vibrating Screen Execution: Non Vibrating Screen Execution
  • Data from Schaeffler (medias):
    • Width (b) mm: 108
    • Radial Static Load Rating C0r (N): 2360000
    • Radial Dynamic Load Rating Cr (N): 1840000
    • Basic static load rating, radial (C 0r): 2360000.0000
    • Limiting speed (n G): 2140
    • Reference speed (n ϑr): 1350
    • ECLASS number: 23-05-09-11
    • ECLASS2 number: 23-05-09-11
    • Medias description: Spherical roller bearings 222..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
    • Suffix description: BE, Maximum Capacity Design, XL, X-Life, K, Tapered Bore, Taper 1:12

22244-BE-XL-K FAG is a high-quality industrial bearing suitable for various applications in industries such as automotive, mining, and construction. This item is available for purchase at PLC2Day.
