Eaton M22-K10 Contact Element

Description

The Eaton M22-K10 is a high-quality, front-mounting contact element from the RMQ-Titan series. This component provides a single normally open (N/O) contact, designed for reliable performance in industrial control applications. It features user-friendly screw terminals for secure wiring and is compatible with the entire M22 modular pushbutton range. Order now from PLC2Day for expert support and fast delivery.

Specifications

• Manufacturer: Eaton
• Type: M22-K10
• Part Number: 216378
• Contact Configuration: 1 Normally Open (N/O)
• Connection Type: Screw terminals
• Mounting: Front fixing
• Rated Insulation Voltage (Ui): 500V
• Rated Impulse Withstand Voltage (Uimp): 6 kV
• AC-15 Rating: 6A at 230V, 4A at 400V
• DC-13 Rating: 3A at 24V, 0.6A at 110V
• Standard: IEC/EN 60947-5-1

Application

This contact element is ideal for use with pushbuttons, selector switches, and indicator lights in industrial control panels, machinery, and automation systems to control motor starters, relays, and PLCs.

Country of Origin

Made in Germany.

CO2 Impact

By purchasing this pre-owned item, you are helping to reduce industrial waste and avoid the CO2 emissions associated with new manufacturing, estimated at 1.2 kg for this product.

Availability

In stock and ready for immediate dispatch.

FAQ

The M22-K10 is a Normally Open (N/O) contact, meaning the circuit is open until the actuator is pressed. The M22-K01 is a Normally Closed (N/C) contact, where the circuit is closed until actuated.

The screw terminals on the M22-K10 are designed to accept solid or stranded wire sizes from 0.75 to 2.5 mm squared (AWG 18-14).

Yes, up to three M22-K contact elements can be clipped onto the back of an M22 mounting adapter, allowing for multiple contact configurations in a compact space.
