Eaton Contact Element 1NC M22-K01

Description

The Eaton M22-K01 is a high-quality contact element designed for the RMQ-Titan series of 22.5 mm modular pushbuttons. This unit provides a single normally closed (NC) contact and features user-friendly Cage Clamp terminals for fast, secure, and vibration-proof wiring. It is designed for front mounting, making installation straightforward in control panels and machinery. Its robust construction ensures long-term reliability in industrial environments.

Specifications

• Manufacturer: Eaton
• Type: M22-K01
• Part Number: 216378
• Contact Configuration: 1 Normally Closed (NC)
• Mounting: Front Mount
• Terminals: Cage Clamp
• Rated Insulation Voltage (Ui): 500V
• Impulse Withstand Voltage (Uimp): 6 kV
• AC-15 Utilization Category: 6A at 230V, 4A at 400V
• DC-13 Utilization Category: 3A at 24V, 0.6A at 110V
• Standards: IEC/EN 60947-5-1

Label Info

• Eaton M22-K01
• IEC 60947-5-1
• Uimp=6kV Ui=500V

Application

The M22-K01 is ideal for use in industrial automation, machine building, and control panel construction. It is typically used in conjunction with pushbuttons, selector switches, and pilot lights to control processes, signal statuses, or as part of safety circuits where a normally closed contact is required.

Country of Origin

Made in Germany.

CO2 Impact

By purchasing a refurbished or surplus part like this Eaton M22-K01, you are actively contributing to a more sustainable circular economy. Reusing this component avoids the production of a new one, saving an estimated 1.0 kg of CO2. This saving is comparable to the emissions from driving a standard car for 5 kilometers.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

What is the difference between the M22-K01 and the M22-K10?

Answer: The last two digits indicate the contact configuration. The M22-K01 has one normally closed (NC) contact and zero normally open contacts. Conversely, the M22-K10 has one normally open (NO) contact and zero normally closed contacts. The actuator color also differs, with red typically indicating NC (K01) and green indicating NO (K10).

Can I stack multiple M22-K01 contact blocks on a single M22 pushbutton actuator?

Answer: Yes, the Eaton M22 series is modular. You can stack up to six contact elements in total on a single M22 operator head, allowing for complex circuit control from one button.

What are Cage Clamp terminals and what is their advantage?

Answer: Cage Clamp terminals are a type of screwless connection technology. You insert the stripped wire into an opening and a spring-loaded clamp provides constant, secure pressure. The main advantages are faster installation time, resistance to vibration, and a reliable connection that does not require periodic retightening.
