Description: AVENTICS™ E/P pressure regulator, Series ED07 R414000691, Product Info: ControlDirectly controlled, Regulation range min.0 bar, Regulation range max.6 bar, Working pressure min.0.5 bar, Working pressure max8 bar, Hysteresis< 0,03 bar, MediumCompressed air, Nominal flow Qn1300 l/min, Min. ambient temperature5 °C, Max. ambient temperature50 °C, Min. medium temperature5 °C, Max. medium temperature50 °C, DC operating voltage24 V, Max. current consumption1400 mA, Protection classIP65, Permissible ripple5%, Max. particle size50 µm, Oil content of compressed air min.0 mg/m³, Oil content of compressed air max.1 mg/m³, Type Poppet valve, Mounting orientationα = 0 ... 90° ±β = 0 ... 90°, CertificatesCE declaration of conformity, Electrical connection sizevia signal connection, Signal connectioninput and output, Signal connection Plug, Label Info: AVENTICS, MNR: R414000691, 1 Stück, FD:18W19, Made in Germany /, 7291

• Description: AVENTICS™ E/P pressure regulator, Series ED07 R414000691
• Product Info: ControlDirectly controlled
• Regulation range min. 0 bar
• Regulation range max. 6 bar
• Working pressure min. 0.5 bar
• Working pressure max 8 bar
• Hysteresis < 0.03 bar
• Medium: Compressed air
• Nominal flow Qn 1300 l/min
• Min. ambient temperature 5 °C
• Max. ambient temperature 50 °C
• Min. medium temperature 5 °C
• Max. medium temperature 50 °C
• DC operating voltage 24 V
• Max. current consumption 1400 mA
• Protection class IP65
• Permissible ripple 5%
• Max. particle size 50 µm
• Oil content of compressed air min. 0 mg/m³
• Oil content of compressed air max. 1 mg/m³
• Type: Poppet valve
• Mounting orientation: α = 0 ... 90° ±β = 0 ... 90°
• Certificates: CE declaration of conformity
• Electrical connection size: via signal connection
• Signal connection: input and output
• Signal connection: Plug
• Label Info: AVENTICS, MNR: R414000691, 1 Stück, FD:18W19, Made in Germany / 7291

R414000691 Aventics

Manufacturer: Aventics

Item Code: R414000691

This high-quality item from Aventics is suitable for a variety of industrial applications such as automation, packaging, conveyors, HVAC, and more. Available for purchase at PLC2Day.

For more items from Aventics in stock, visit Aventics page.

Visit the official website for more product details: Aventics
