ASCO G1/8 Flow Control Valve 34600107

Description

The ASCO 34600107 is a high-quality, unidirectional flow control valve designed for precise regulation of airflow in pneumatic systems. This banjo-style valve allows for fine adjustment of cylinder speed by controlling the flow rate in one direction, while allowing free flow in the reverse direction. Its robust brass construction ensures durability and reliable performance in demanding industrial environments.

Specifications

• Manufacturer: ASCO
• Part Number: 34600107
• Type: Unidirectional Flow Control Valve (Throttle Valve)
• Connection: G1/8 inch male thread
• Tubing Compatibility: For DN5 tubing
• Body Material: Brass
• Operating Pressure: 1 to 10 bar
• Operating Temperature: -10 deg C to +60 deg C

Label Info

• Article Number (Artnr): 200243430
• Description: smoorventiel dn5 - 1/8inch 34600107

Application

This valve is ideally suited for applications requiring precise speed control of pneumatic actuators and cylinders. It is commonly used in industrial automation, material handling, packaging machinery, and robotics to ensure smooth and controlled motion.

Country of Origin

This product is manufactured in the European Union.

CO2 Impact

Choosing a reused ASCO flow control valve like this one avoids the CO2 emissions associated with manufacturing a new part, estimated at 0.2 kg. This saving is comparable to driving an average car for 1 kilometer.

Availability

This item is in stock and ready for immediate dispatch. All our products are tested and guaranteed to be fully functional. Order now from PLC2Day for expert support and fast delivery.

FAQ

Question?

What type of tubing is compatible with this valve?

This valve is designed for use with standard pneumatic tubing with a nominal diameter (DN) of 5 mm. Materials such as Polyamide (PA), Polyurethane (PU), and Polyethylene (PE) are typically compatible.

Is this a bi-directional or uni-directional flow controller?

This is a uni-directional flow controller, also known as a throttle-check valve. It restricts flow in one direction (adjustable via the screw) and allows free, unrestricted flow in the opposite direction.

What is the recommended installation orientation?

For controlling the speed of a cylinder, this valve is typically installed on the cylinder's exhaust port. This configuration, known as 'meter-out' control, provides more stable and consistent cylinder movement by controlling the rate at which air can exit.
