AKN TSNX 522/619 ZA Taconite Seal for Bearing Housings

Description

This is the AKN TSNX 522/619 ZA, a heavy-duty taconite seal designed for superior bearing protection in harsh and contaminated environments. As a non-contact labyrinth seal, it effectively prevents the ingress of solid and liquid contaminants while retaining bearing lubricant. It is suitable for use in standard SNL 522 and SNL 619 series plummer block housings.

Specifications

• Manufacturer: AKN
• Part Number: TSNX 522/619 ZA
• Product Type: Taconite Seal (Labyrinth Seal)
• Compatible Housing Series: SNL 522, SNL 619
• Sealing Principle: Multi-stage, non-contact labyrinth
• Primary Material: Steel and Elastomer

Label Info

• Brand: akn
• Model: TSNX 522/619 ZA
• Batch Code: H247

Application

This seal is ideal for demanding applications in industries such as mining, quarrying, cement production, pulp and paper, and steel manufacturing where bearings are exposed to extreme contamination.

Country of Origin

Germany

CO2 Impact

Opting for this component saves an estimated 2.0 kg of CO2 compared to a new production. This saving is equivalent to the emissions from a 10 km car journey.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

Taconite seals provide superior protection in highly contaminated environments. Their multi-stage labyrinth design creates a difficult path for contaminants like dust, dirt, and water to enter the bearing housing, while a grease-filled cavity acts as an additional barrier. This is far more effective than simple contact seals, significantly extending bearing life in harsh applications.

Yes, it is recommended to fill the labyrinth cavity with grease. A standard lithium-based grease is usually sufficient, but for optimal performance, you should use a grease compatible with the bearing lubricant. This grease barrier purges contaminants and prevents them from reaching the bearing.

Taconite seals are non-contact labyrinth seals, which means they do not generate frictional heat like contact seals do. This makes them suitable for higher speeds compared to many contact seal types. However, for extremely high-speed applications, you should always consult the manufacturer's speed rating to ensure it meets your equipment's requirements.
