AKN GLI POM 10010560 Plain Bearing Bushing

Description

This is an AKN GLI POM series plain bearing bushing, part number 10010560. This component is designed for applications requiring low friction and high wear resistance under marginally lubricated conditions. The composite structure of steel, sintered bronze, and a POM sliding layer makes it suitable for heavy-duty industrial machinery.

Specifications

• Manufacturer: AKN
• Part Number: GLI POM 10010560
• Type: Plain Bearing / Bushing
• Material: Steel / Sintered Bronze / POM (CSB-20 equivalent)
• Inner Diameter: 100 mm
• Outer Diameter: 105 mm
• Length: 60 mm

Label Info

• Marking on part: CSB-20 10060

Application

Ideal for pivot points in hydraulic cylinders, material handling equipment, agricultural machinery, and construction vehicles where oscillating or rotating movements are common.

Country of Origin

Germany

CO2 Impact

By reusing this part, you avoid the production of a new one, saving approximately 0.76 kg of CO2. This is equivalent to the energy needed to fully charge a smartphone more than 90 times.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

What is the main advantage of the POM sliding surface?
The Polyoxymethylene (POM) surface has a very low coefficient of friction and is indented with lubrication pockets. This design allows it to operate effectively with minimal initial lubrication, holding grease for extended periods and reducing maintenance needs.

Is this bearing suitable for dry-running conditions?
While it excels in marginally lubricated applications, the GLI POM (DX-type) bearing is not recommended for completely dry-running conditions. It requires some form of lubrication (grease or oil) to achieve its optimal performance and lifespan.

How should this wrapped bushing be installed?
This is a split, wrapped bushing and should be press-fitted into a rigid housing with the correct tolerances. The split (butt joint) allows for easier installation and should be positioned away from the main load zone to ensure maximum load-bearing capacity.
