AKN Flanged Sliding Bearing 8x10x6mm

Description

This is a set of high-quality flanged sliding bearings, model BMF 081006 from AKN. These self-lubricating bushings are designed for maintenance-free operation in a wide variety of industrial applications. The composite structure, typically a steel backing with a sintered bronze layer and a PTFE sliding surface, provides excellent low-friction performance and high load capacity.

Specifications

• Manufacturer: AKN
• Type: BMF 081006
• Article Number: 03435381
• Inner Diameter (d1): 8 mm
• Outer Diameter (d2): 10 mm
• Length (L1): 6 mm
• Flange Diameter (d3): 14 mm
• Material: Composite (Steel/Bronze/PTFE)

Label Info

• Brand: akn
• Part Number: AKN BMF 081006 GLIJLAGERKRAAGBUS
• Article No: 03435381

Application

Ideal for use in applications with pivoting, rotating, or oscillating movements where space is limited and maintenance is difficult. Common uses include automotive components, hydraulic cylinders, material handling equipment, and general machinery.

CO2 Impact

Choosing these pre-owned components over new ones avoids the emission of approximately 0.03 kg of CO2, contributing to a more sustainable industrial practice. This saving is equivalent to charging a smartphone several times.

Availability

This item is in stock and ready for immediate dispatch. Order now from PLC2Day for expert support and fast delivery.

FAQ

The main advantages include self-lubricating properties for maintenance-free operation, very low friction, a wide operating temperature range, and good chemical resistance.

For optimal performance and a secure press-fit, it is recommended to use a shaft with an h8 tolerance and a housing bore with an H7 tolerance. This ensures the correct running clearance after installation.

Yes. While specifically designed for dry running conditions, applying a small amount of grease or oil during assembly can help reduce friction and wear during the initial break-in period or in very low-speed, high-load scenarios.
